Tiso Gate-STE

  • Disabled and trolley access
  • Durable housing for high-traffic areas
  • Affordable and high-quality construction
  • Suitable for indoor and outdoor installations
  • Compatible with TiSO Frame-M mobile platform
  • Adjustable passage width
  • Wired remote control included

Description

Mechanical Gate-STE with electromagnetic lock is effective entrance solution to control one-way pedestrian traffic. Telescopic tubular leaf can be up to 1000 mm wide that makes it ideal for a site where entrance space is not indicated. The gate is equipped with electromagnetic lock that blocks gate in closed position. To enter in the access permitted direction you have to push the gate. Once the passage is complete, the leaf automatically returns by spring closer to the start position. Fail-safe operation (free open upon power loss) makes this gate possible to use as an emergency exit. Gate-STE is operated by the remote control panel (included in standard set). Gate-STE can be integrated with any access control system if required.





Model NameGate-STE 700 / Gate-STE 1050
Width800 / 1240 mm
Length225 mm
Height1000 mm
Passage width700 / 1050 mm
MechanismElectromechanical
Blocking systemSingle electromagnetic brake
Operaon modeCW (90°) and CCW (90°)
Emergency modeFree exit/entry (gate is opening automatically)
MTTR< 25 min
Maximum power consumption60 W
