Tiso Highway-NG

  • BMDrive® BLDC motor for reliable, maintenance-free operation
  • BMDrive® safety system protects glass leaves from forced damage
  • ToothLock® locking system with HiSecurity & LowNoise modes
  • Digital force & speed control with safety sensors
  • Passenger and luggage detection
  • Compatible with various access control systems
  • Low power consumption
  • Wired remote control included

Description

HighWay-NG – perfectly combines modern aesthetics and functionality. The glass leaves made of impact-resistant glass provide a feeling of transparency and make it ideal for the most demanding building entrances. High leaves exclude the possibility of unauthorized passage, but also prevent the transfer of anything above the turnstile, and provide high visibility of pedestrian progress. The sophisticated sensor systems ensure a high level of object security with simultaneous regard to pedestrian safety.





Model NameHighWay-NG
Cabinet width1300 mm
Cabinet length1205 mm
Cabinet height2228 mm
Passage width1000 mm
Opening/closing time1.5 sec
MechanismBMDrive® servodrive (BLDC)
Blocking systemToothLock®
Emergency modeFree entry/exit (leaves are opened automatically)
Power failFail safe (leaves could be opened manually—standard)
MCBF10,000,000 cycles
MTTR< 25 min
Maximum power consumption160 W
