Tiso Sesame-L

  • High-security design with advanced force control
  • Fully welded or disassembled supply options
  • Low-noise operation
  • Durable housing for high-traffic areas
  • Low power consumption
  • Compatible with various access control systems
  • Wired remote control included
  • Fail-safe rotor unlocking during power failure

Description

Sesame-L is a one-lane type of full-height turnstile gate with servo-driven mechanism. It ensures vandal-proof security level to large variety of possible applications: stadiums, factories, parks, premises with highest security requirements, etc. Strength and durability is granted by robust fully welded design. On the other hand, attractive shipment assembly modification of automatic barrier gate is also available.





Model NameSesame-L X-rotor / Sesame-L Y-rotor
Cabinet width1254 / 1430 mm
Cabinet length1300 / 1168 mm
Cabinet height2300 mm
Passage width535 / 650 mm
MechanismServo-drive (Triservo-M)
Blocking systemTwo electromechanical stop catches
Emergency modeFree pass in both directions
Power failFail safe (rotor is unlocked—standard)
MCBF10,000,000 cycles
MTTR< 25 min
Maximum power consumption160 W
